Two-way diverters
USING
A two-way diverter (hose switch) is designed to change the direction of movement of bulk material flow and to divide the flow into several directions. The manufacturer produces more than 30 models of two-way diverters depending on the type of control (manual or automatic), the angle of rotation, the size of the conditional passage section, and the need for lining (abrasion-resistant or anti-adhesive). In general, carbon steel with a thickness of 4 or 5 mm is used to manufacture the housing of two-way diverters, but they can also be made of special steels.
technical specifications
| Parameters | Type A | Type B | Type C | Type D | Type E | Тype F |
|---|---|---|---|---|---|---|
| Conditional passage section, mm | 200х200 | 300х300 / 400х400 | 200х200 | 400х400 / 500х500 | 200x200 / 300х300 | 400х400 |
| Presence of lining, lining material | UHMW-PE | Castolin CDP 4666 / no one | Castolin CDP 4666 | Castolin CDP 4666 / UHMW-PE / Hardox 400 / no one | Castolin CDP 4666 / no one | Castolin CDP 4666 |
| Control | electro- pneumatic | manual / electro- pneumatic | manual | manual / electro- pneumatic / electric (motor reducer) | electro- pneumatic | electro- pneumatic |
| Construction of transfer element | plate | plate | plate | plate / tray | plate | plate |
| Rotation angle° | 40, symmetrical | 45 | 50 | 60, symmetrical | 90, symmetrical | 90, symmetrical |
| Number of switch positions / directions | 2 | 2 | 2 | 2 | 2 | 3 |
