Vibrating feeders
USING
Vibratory feeders of the PV-8, PV-15 series are designed for supply of free-flowing fine-grained and lump non-caking and non-sticking materials with mesh size up to 20 mm with bulk density up to 2 g/sm3 in workshops at environmental air temperature of -30° to 50°.
technical specifications
| Parameters | PV8 – 0,36 / 0,9 | PV8 – 0,5 / 1,2 | PV15 – 0,5 / 1,2 | PV8 – 0,5 / 1,6 | PV8 – 0,5 / 1,9 | PV8 – 0,8 / 1,8 |
|---|---|---|---|---|---|---|
| Width of vibratory chute, mm | 364 | 474 | 474 | 474 | 474 | 780 |
| Height of vibratory shute, mm | 147 | 260 | 260 | 260 | 260 | 274 |
| Dimensions of loading part | 300 х 300 | 450 х 450 | 450 х 450 | 450 х 450 | 450 х 450 | 700 х 700 |
| Inclination of vibratory chute | 8 | 8 | 15 | 8 | 8 | 8 |
| Power supply voltage, V | 380 ± 38 | 380 ± 38 | 380 ± 38 | 380 ± 38 | 380 ± 38 | 380 ± 38 |
| Output for sand with density of 1,5 t/m3 with installation of balance weight on 60 (80)% | 20 (30) | 30 (40) | 36 (48) | 30 (40) | 30 (40) | 64 (80) |
| Vibrator, type | MVE 400/15 | MVE 500/3 | MVE 500/3 | MVE 500/3 | MVE 1200/3 | MVE 2300/3 |
| Rated input , kW | 0,6 | 1,0 | 1,0 | 1,0 | 1,9 | 4,8 |
| Weight of vibratory feeder, kg | 125 | 177 | 177 | 248 | 300 | 700 |
